MAXXAIR™ | MSX Series | MSX134

Take your automotive servicing to the next level with MAXXAIR™ MSX134, the pinnacle of RRR Management Centers. Accelerate recovery time by 30% with its High-Capacity Oilless Compressor, paired with a user-friendly 7” Color Touch-Screen display for peak productivity.

General Details


MSX134 With Oil Injection R-134a

The MSX134 sets the standard for the next generation of Refrigerant Recovery, Recycling, and Recharge (RRR) Management Centers. Designed to elevate your workflow with unparalleled efficiency and precision performance, the MSX134 is engineered to exceed expectations. Featuring a High-Capacity Oilless Compressor, the MSX134 accelerates recovery time by up to 30% faster than the competition, as confirmed by rigorous internal tests. Navigate through operations with the intuitive 7” Color Touch-Screen display, ensuring seamless interaction and ease of use. Experience MSX precision performance with increased productivity in the MSX134.

Precision performance with increased productivity:

    • Fully Automatic or User-Selected Manual Processes
    • 7” Color Touch-Screen display
    • Wireless network printing
    • High-Capacity oilless compressor
    • Includes 30lb tank (upgradeable to 50lb)
    • Onboard oil injection
    • 2-Year Full Coverage Warranty
Power115V 60Hz
Compressor2/3 HP twin cylinder oilless
Vacuum pump2-Stage, 2 CFM, 1/3 HP
Gauges3.5” Low-side, 30 in/Hg to 250 psi; High-side, 0 to 600 psi
Hoses10 Ft. (3.0 m), Barrier Type
Maximum recovery rateUp to 1 Lb (0.453 kg) per minute
Storage tank30 Lb. standard, upgradable to 50 Lb.
Display7” Color Touch-Screen
ConstructionHeavy-duty Steel Frame Construction
Operating temp range50°F to 122° (10°C to 50°C)
Operating humidity range0% to 95% (Non-Condensing)
Dimensions43.6” x 22.6” x 28.9”
Gross weight208 lb. (including packaging)
WarrantyMAXXAIRTM 2-Year Full Coverage Warranty
